INVERTER DC MMA WELDING MACHINE
【Model 】:MMA250I
【Brief 】:

Compact design ,equipped with imported IGBT device of high power

Rugged design with portable light weight 4KGS

【Series】:STICK(SMAW)
Close
    Feedback Form:
    E-mail:     *
    Message:     *


Compact design ,equipped with imported IGBT device of high power

Rugged design with portable light weight 4KGS

High duty cycle and most cost-effective

Work with 1.6-3.2 rod



Model MMA200G
MMA250I
Input Power Voltage(v)
AC220V+15%   1PH
AC220V+15% 1PH
Rated input power capacity(KVA)
3.8
5.3
Input voltage frequency(HZ)
50/60
50/60
Rated input current(A)
17.1
24.2
No-load voltage(V)
60
60
Output current range(A)
30-120
30-160
Rated output volatage(V)
24.8
26.4
Duty cycle(%)
60
60
Insulation class
F
F
Protection class
IP21S
IP21S
Diameter of rod
1.6-3.2
1.6-4.0
Power factor
0.93
0.93
Efficiency(%)
85 85
Weight(KG)
4
4.5
Diamension(mm)
283x133x198
283x133x198



Metal workshops

Repair and maintenance
